Panel dividing saws SAWTEQ S-410 lifiting table
Panel dividing saws SAWTEQ S-410 lifiting table
In the SAWTEQ S-410, HOMAG offers a horizontal panel saw with automatic feed system that really speeds up the cutting process.
The SAWTEQ S-410 is a high-performance saw for processing larger volumes of panels in finish cut quality. The saw works reliably and precisely at high speed and delivers high throughput. This is achieved by, among other things, the lifting table for automatic feeding.
Highlights
Operator comfort and performance are ensured by the new control panel with additional position on the pressure beam, intelliGuide operator assistance system and quickTip - the assistant for an optimally set machine
With the new toleranceCheck tolerance measurement, you produce permanently at a high quality level
Images
-
![]()
Fully automatic angle cuts thanks to automatic calculation and adjustment of the angle – fast, efficient and with maximum care of material (option). -
![]()
combiTec saves material, time, money and manual work steps: due to automatic recuts during the regular cutting process (option). -
![]()
Destacking concept: guides the operator from depositing the first part to forming the perfect stacked pallet (option). -
![]()
Scissor lift pallet truck HuGo: equipped with automatic height control for ergonomic and intelligent destacking (option). -
![]()
The panel labeling system saves time and guides the operator (option). -
![]()
The Power Concept Premium boosts output by up to 40 %, significantly shortens work cycles and reduces unit costs (option). -
![]()
The postforming unit ensures a chip-free cut for softforming and postforming panels (option). -
![]()
Turning device for headcuts: significantly increases performance with suiTable cutting patterns and reduces the amount of handling required (option). -
![]()
Cutting pattern optimization in the office – for precise project control, efficient cutting processes, cost control and faster pricing (option). -
![]()
The intuitive Operator Assistance System LED visually guides the operator through the processing steps by means of an LED light strip (option).
Features
-
Maintenance-free lifting table for automatic feeding from the rear
-
Central side pressure device: integrated directly in the saw carriage for short cycle times
-
Control software CADmatic 5
– Intuitively understandable
– Full HD widescreen multi-touch monitor
– Harmonized user interface powerTouch
– The new 3D assistance graphic supports the operator and is intuitive to operate
– Ready for connection to tapio
– Graphically supported diagnostics -
Ergonomic table height of 920 mm
Technical Data
| Saw blade projection [mm] | 110 (125 as option) |
| Cutting length [mm] | 3,200 / 3,800 / 4,300 / 5,600 |
| Program fence speed [m/min] | up to 90 |
| Saw carriage speed [m/min] | up to 150 (up to 170 as option) |
| Main saw motor [kW] | 50 Hz: 18 (24 as option) 60 Hz: 21 (21 as option) |
| Monitor | 24" full-HD multi-touch display |
| Operating software | CADmatic 5 |
(Previous product name: Panel dividing saw SAWTEQ B-400 | HPL 400)
Software
-
![]()
materialManager Advanced
Proposes optimal parameters automatically on your saw, corresponding to your materials, tools and quality requirements.
-
![]()
CADmatic 5
Simple, intuitive and ergonomic machine operation thanks to the 3D assistance graphic
quickTip—the assistance function for optimal machine settings—proactively makes setting recommendations
Reproduce parts easily, reliably and using a transparent process with the reproduction of parts option in CADmatic
-
![]()
intelliDivide Cutting
Optimization software for cutting processes on saws
Optimization of cutting plans with just a few clicks
Simultaneous calculation of multiple solutions
Videos
Please confirm that when you use YouTube, data such as your IP address, browser identifier and similar may be transmitted to Google.
» Privacy Policy
quickTip - der Assistent für eine optimale Nutzung der Maschinenfunktionen
quickTip ist eine neue, in die HOMAG Sägensteuerung integrierte, Assistenzfunktion für höchste Qualität, Bedienkomfort und Leistung.
-
![]()
Please confirm that when you use YouTube, data such as your IP address, browser identifier and similar may be transmitted to Google.
» Privacy PolicyMaterial in Bewegung – Lager, digitale Assistenzen und weitere Features
Die Gesamtlösung von der Beschickung bis hin zur Abstapelung
-
![]()
Please confirm that when you use YouTube, data such as your IP address, browser identifier and similar may be transmitted to Google.
» Privacy PolicytoleranceCheck: Dauerhaft maß- und winkelhaltige Teile produzieren
Wir zeigen Ihnen, wie Sie die geforderte Maß- und Winkelhaltigkeit von Teilen kontinuierlich sicherstellen – auch bei spannungsbehaftetem Material.
Brochures
Product Comparison
Lifting table saws for cutting
|
|
|
| |
|---|---|---|---|---|
| SAWTEQ S-210 lifiting table | SAWTEQ S-310 | SAWTEQ S-410 lifiting table | SAWTEQ S-510 with lifting table | |
| Cutting length [mm] | 3,200 | 3,800 / 4,300 | 3,200 | 3,800 | 4,300 | 5,600 | 3,200 | 3,800 | 4,300 | 5,600 | 3,200 | 3,800 | 4,300 | 5,600 | 6,500 |
| Saw blade projection [mm] | 65 (optional 80 or 95) | 80 (optional 95) | 110 (optional 125) | 150 (optional 170) |
| Program fence speed [m/min] | up to 80 | up to 90 | up to 90 | up to 90 |
| Saw carriage speed [m/min] | up to 80 (optional up to 120) | up to150 (optional 170) | 150 (optional up to170) | up to 130 (optional 150) |
| Left handed machine possible | - | |||
